验证数据展示

  • WB analysis using 68226-1-Ig (same clone as 68226-1-PBS)

    WB analysis using 68226-1-Ig (same clone as 68226-1-PBS)

    Various lysates were subjected to SDS PAGE followed by western blot with 68226-1-Ig (IMMT antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours. This data was developed using the same antibody clone with 68226-1-PBS in a different storage buffer formulation.

  • IHC staining of mouse heart using 68226-1-Ig (same clone as 68226-1-PBS)

    IHC staining of mouse heart using 68226-1-Ig (same clone as 68226-1-PBS)

    Immunohistochemical analysis of paraffin-embedded mouse heart tissue slide using 68226-1-Ig (IMMT antibody) at dilution of 1:2000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 68226-1-PBS in a different storage buffer formulation.

    Ready-to-use IHC kits available with IMMT antibody included
  • IHC staining of mouse heart using 68226-1-Ig (same clone as 68226-1-PBS)

    IHC staining of mouse heart using 68226-1-Ig (same clone as 68226-1-PBS)

    Immunohistochemical analysis of paraffin-embedded mouse heart tissue slide using 68226-1-Ig (IMMT antibody) at dilution of 1:2000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 68226-1-PBS in a different storage buffer formulation.

    Ready-to-use IHC kits available with IMMT antibody included
  • IF Staining of HeLa using 68226-1-Ig (same clone as 68226-1-PBS)

    IF Staining of HeLa using 68226-1-Ig (same clone as 68226-1-PBS)

    Immunofluorescent analysis of (4% PFA) fixed HeLa cells using IMMT antibody (68226-1-Ig, Clone: 2D2E8 ) at dilution of 1:800 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L), CL594-Phalloidin (red). This data was developed using the same antibody clone with 68226-1-PBS in a different storage buffer formulation.

  • IF Staining of HeLa using 68226-1-Ig (same clone as 68226-1-PBS)

    IF Staining of HeLa using 68226-1-Ig (same clone as 68226-1-PBS)

    Immunofluorescent analysis of (4% PFA) fixed HeLa cells using IMMT antibody (68226-1-Ig, Clone: 2D2E8 ) at dilution of 1:800 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L), CL594-Phalloidin (red). This data was developed using the same antibody clone with 68226-1-PBS in a different storage buffer formulation.

  • FC experiment of HEK-293 using 68226-1-Ig (same clone as 68226-1-PBS)

    FC experiment of HEK-293 using 68226-1-Ig (same clone as 68226-1-PBS)

    1X10^6 HEK-293 cells were intracellularly stained with 0.4 ug Anti-Human IMMT (68226-1-Ig, Clone:2D2E8) and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Mouse IgG2b Isotype Control (66360-3-Ig, Clone: K11B8C4B5) (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C). This data was developed using the same antibody clone with 68226-1-PBS in a different storage buffer formulation.

  • WB analysis of HeLa using 68226-1-Ig (same clone as 68226-1-PBS)

    WB analysis of HeLa using 68226-1-Ig (same clone as 68226-1-PBS)

    WB result of IMMT antibody (68226-1-Ig; 1:30000; incubated at room temperature for 1.5 hours) with sh-Control and sh-IMMT transfected HeLa cells. This data was developed using the same antibody clone with 68226-1-PBS in a different storage buffer formulation.

  • Cytometric bead array standard curve of MP50515-1

    Cytometric bead array standard curve of MP50515-1

    Cytometric bead array standard curve of MP50515-1, IMMT Monoclonal Matched Antibody Pair, PBS Only. Capture antibody: 68226-1-PBS. Detection antibody: 68226-2-PBS. Standard:Ag0102. Range: 0.098-100 ng/mL.

  • Cytometric bead array standard curve of MP50515-2

    Cytometric bead array standard curve of MP50515-2

    Cytometric bead array standard curve of MP50515-2, IMMT Monoclonal Matched Antibody Pair, PBS Only. Capture antibody: 68226-3-PBS. Detection antibody: 68226-1-PBS. Standard:Ag0102. Range: 0.098-100 ng/mL.

  • Featured Product
  • KD/KO验证

IMMT Monoclonal antibody, PBS Only (Capture/Detector)

IMMT Monoclonal Antibody for WB, IHC, IF/ICC, FC (Intra), Cytometric bead array, Indirect ELISA
Cat No. 68226-1-PBS

产品说明书

CloneNo. 2D2E8

宿主/亚型

Mouse / IgG2b

种属反应性

human, mouse, rat

应用

WB, IHC, IF/ICC, FC (Intra), Cytometric bead array, Indirect ELISA

别名

MINOS2, MICOS complex subunit MIC60, MIC60, HMP, Cell proliferation-inducing gene 4/52 protein

缓冲液配方:  PBS Only
PBS and Azide
PBS Only
偶联物:  Unconjugated
规格:

-/ -

点击咨询售前客服

点击咨询售后客服

Planning an IHC experiment? We recommend our IHCeasy IMMT Ready-To-Use IHC Kit. IMMT primary antibody included.

产品信息

68226-1-PBS targets IMMT as part of a matched antibody pair:

MP50515-1: 68226-1-PBS capture and 68226-2-PBS detection (validated in Cytometric bead array)

MP50515-2: 68226-3-PBS capture and 68226-1-PBS detection (validated in Cytometric bead array)

Unconjugated mouse monoclonal antibody pair in PBS only (BSA and azide free) storage buffer at a concentration of 1 mg/mL, ready for conjugation.

This conjugation ready format makes antibodies ideal for use in many applications including: ELISAs, multiplex assays requiring matched pairs, mass cytometry, and multiplex imaging applications.Antibody use should be optimized by the end user for each application and assay.

经测试应用 WB, IHC, IF/ICC, FC (Intra), Cytometric bead array, Indirect ELISA Application Description
经测试反应性 human, mouse, rat
免疫原 IMMT fusion protein Ag0102 种属同源性预测
宿主/亚型 Mouse / IgG2b
抗体类别 Monoclonal
产品类型 Antibody
全称 inner membrane protein, mitochondrial (mitofilin)
别名 MINOS2, MICOS complex subunit MIC60, MIC60, HMP, Cell proliferation-inducing gene 4/52 protein
计算分子量 90 kDa
观测分子量90 kDa
GenBank蛋白编号BC002412
基因名称 IMMT
Gene ID (NCBI) 10989
偶联类型 Unconjugated
形式 Liquid
纯化方式Protein A purification
UNIPROT IDQ16891
储存缓冲液 PBS only , pH 7.3
储存条件Store at -80°C.
The product is shipped with ice packs. Upon receipt, store it immediately at -80°C

背景介绍

IMMT (also known as mitofilin) is an inner mitochondrial membrane protein that is preferentially expressed in heart tissue and is commonly used as the marker for mitochondria. Mitofilin is known to be a critical organizer of mitochondrial cristae morphology and is indispensable for normal mitochondrial function. Three isoforms of mitofilin exist due to the alternative splicing. All three proteins of 87kD, 89kD and 80kD can be detected in immunoblot analysis with this antibody.
