CoraLite®594-conjugated transgelin/SM22 Monoclonal antibody

transgelin/SM22 Monoclonal Antibody for IF-P

Host / Isotype

Mouse / IgG1

Reactivity

human, rat, pig, mouse

Applications

IF-P

Conjugate

CoraLite®594 Fluorescent Dye

CloneNo.

2A10C2

Cat no : CL594-60213

Print datasheet

Synonyms

22 kDa actin binding protein, DKFZp686P11128, Protein WS3 10, SM22, SM22 alpha, SM22alpha, SMCC, Smooth muscle protein 22 alpha, TAGLN, TAGLN1, transgelin, TRANSGELIN 1, transgelin/SM22, WS3 10

验证数据展示

  • IF Staining of mouse heart using CL594-60213

    IF Staining of mouse heart using CL594-60213

    Immunofluorescent analysis of (4% PFA) fixed mouse heart tissue using CL594-60213 (transgelin/SM22 antibody) at dilution of 1:100.

  • IF Staining of mouse heart using CL594-60213

    IF Staining of mouse heart using CL594-60213

    Immunofluorescent analysis of (4% PFA) fixed mouse heart tissue using CL594-60213 (transgelin/SM22 antibody) at dilution of 1:100.

经过测试的应用

Positive IF-P detected inmouse heart tissue
Planning an IHC experiment? We recommend our IHCeasy TAGLN Ready-To-Use IHC Kit. TAGLN primary antibody included.
For other applications, we recommend the unconjugated version of this antibody, 60213-1-Ig

推荐稀释比

ApplicationDilution
Immunofluorescence (IF)-PIF-P : 1:50-1:500
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

产品信息

CL594-60213 targets transgelin/SM22 in IF-P applications and shows reactivity with human, rat, pig, mouse samples.

Tested Applications IF-P Application Description
Tested Reactivity human, rat, pig, mouse
Immunogen transgelin/SM22 fusion protein Ag0764 种属同源性预测
Host / Isotype Mouse / IgG1
Class Monoclonal
Type Antibody
Full Name transgelin
Synonyms 22 kDa actin binding protein, DKFZp686P11128, Protein WS3 10, SM22, SM22 alpha, SM22alpha, SMCC, Smooth muscle protein 22 alpha, TAGLN, TAGLN1, transgelin, TRANSGELIN 1, transgelin/SM22, WS3 10
Calculated Molecular Weight 22 kDa
Observed Molecular Weight 18+22 kDa
GenBank Accession NumberBC004927
Gene Symbol transgelin/SM22
Gene ID (NCBI) 6876
RRIDAB_2883444
Conjugate CoraLite®594 Fluorescent Dye
Excitation/Emission Maxima Wavelengths588 nm / 604 nm
Form Liquid
Purification MethodProtein G purification
UNIPROT IDQ01995
Storage Buffer PBS with 50% Glycerol, 0.05% Proclin300, 0.5% BSA, pH 7.3.
Storage ConditionsStore at -20°C. Avoid exposure to light. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage.

背景介绍

The transgelin family is a group of proteins that belong to 22 kDa actin-related corpnin superfamily. Of all three isoforms, transgelin 1 is the best characterized. Transgelin 1, also known as SM22 alpha, is a specific marker for differentiated smooth muscle cells. Transgelin 2, also known as SM22 beta, is expressed by both smooth muscle and non-smooth muscle cells in a temporally and spatially regulated pattern. Trangenlin 3, also known as NP25, is only found in highly differentiated neuronal cells.

实验方案

Product Specific Protocols
IF protocol for CL594 transgelin/SM22 antibody CL594-60213Download protocol
Standard Protocols
Click here to view our Standard Protocols
