  • FC experiment of HeLa using CL488-15999

    FC experiment of HeLa using CL488-15999

    1X10^6 HeLa cells were intracellularly stained with 0.4 ug CoraLite® Plus 488 Anti-Human ATP5F1 (CL488-15999) (red), or 0.4 ug CoraLite® Plus 488-conjugated Rabbit IgG control Rabbit PolyAb (CL488-30000, Clone: ) (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

  • IF Staining of HepG2 using CL488-15999

    IF Staining of HepG2 using CL488-15999

    Immunofluorescent analysis of (-20°C Ethanol) fixed HepG2 cells using CoraLite® Plus 488 ATP5F1 antibody (CL488-15999) at dilution of 1:200, CL594-Phalloidin (red).

  • IF Staining of HeLa using CL488-15999

    IF Staining of HeLa using CL488-15999

    Immunofluorescent analysis of (-20°C Ethanol) fixed HeLa cells using CoraLite® Plus 488 ATP5F1 antibody (CL488-15999) at dilution of 1:600.

CoraLite® Plus 488-conjugated ATP5F1 Polyclonal antibody

ATP5F1 Polyclonal Antibody for IF/ICC, FC (Intra)
Cat No. CL488-15999

产品说明书

宿主/亚型

Rabbit / IgG

种属反应性

human, mouse

应用

IF/ICC, FC (Intra)

别名

ATP5PB, ATP5F 1, ATP synthase subunit b, ATP synthase proton-transporting mitochondrial F(0) complex subunit B1, ATP synthase peripheral stalk-membrane subunit b

缓冲液配方:  PBS and Azide
PBS and Azide
偶联物:  CoraLite® Plus 488
规格:

-/ -

点击咨询售前客服

点击咨询售后客服

经过测试的应用

Positive IF/ICC detected inHepG2 cells, HeLa cells
Positive FC (Intra) detected inHeLa cells
For other applications, we recommend the unconjugated version of this antibody, 15999-1-AP

推荐稀释比

应用推荐稀释比
Immunofluorescence (IF)/ICCIF/ICC : 1:50-1:500
Flow Cytometry (FC) (INTRA)FC (INTRA) : 0.40 ug per 10^6 cells in a 100 µl suspension
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

产品信息

CL488-15999 targets ATP5F1 in IF/ICC, FC (Intra) applications and shows reactivity with human, mouse samples.

经测试应用 IF/ICC, FC (Intra) Application Description
经测试反应性 human, mouse
免疫原 ATP5F1 fusion protein Ag8571 种属同源性预测
宿主/亚型 Rabbit / IgG
抗体类别 Polyclonal
产品类型 Antibody
全称 ATP synthase, H+ transporting, mitochondrial F0 complex, subunit B1
别名 ATP5PB, ATP5F 1, ATP synthase subunit b, ATP synthase proton-transporting mitochondrial F(0) complex subunit B1, ATP synthase peripheral stalk-membrane subunit b
计算分子量 256 aa, 29 kDa
观测分子量 25-30 kDa
GenBank蛋白编号BC005366
基因名称 ATP5F1
Gene ID (NCBI) 515
RRIDAB_3083981
偶联类型 CoraLite® Plus 488 Fluorescent Dye
最大激发/发射波长493 nm / 522 nm
形式 Liquid
纯化方式Antigen affinity purification
UNIPROT IDP24539
储存缓冲液 PBS with 50% glycerol, 0.05% Proclin300, 0.5% BSA , pH 7.3
储存条件Store at -20°C. Avoid exposure to light. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage.

背景介绍

ATP5F1(ATP synthase subunit b) belongs to the eukaryotic ATPase B chain family. The ATP5F1 gene encodes subunit B of the mitochondrial ATP synthase Fo unit, which contains 214-amino acid with a 42-amino acid import signal(PMID:1831354). Mitochondrial membrane ATP synthase(F1F0 ATP synthase or Complex V) produces ATP from ADP in the presence of a proton gradient across the membrane which is generated by electron transport complexes of the respiratory chain.

实验方案

Product Specific Protocols
IF protocol for CL Plus 488 ATP5F1 antibody CL488-15999Download protocol
FC protocol for CL Plus 488 ATP5F1 antibody CL488-15999Download protocol
Standard Protocols
Click here to view our Standard Protocols
